China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of tracked skid steer loader in China. With abundant experience, we warmly welcome you to buy cheap tracked skid steer loader made in China here from our factory. For price consultation, contact us.
Key Features
Track Grounding Design
Large track contact area significantly reduces ground pressure, allowing the machine to operate smoothly and stably on soft, muddy, swampy, or low-load terrain without sinking.
Strong Off-Road Capability
High friction between track teeth and the ground provides excellent traction, improving climbing performance and preventing slipping on hills, farmland, wetlands, and uneven surfaces.
Lightweight & Flexible Structure
Compact and lightweight design enables easy maneuverability in narrow and complex job sites, delivering high efficiency even in space-limited environments.
High Cost-Effectiveness
Optimized for multi-purpose operations, this machine balances loading capacity, performance, and operating cost, making it an ideal solution for small to medium-scale projects.
Main Applications
- Construction projects & road building
- Rural infrastructure & agricultural operations
- Warehousing & material handling
- Emergency rescue & municipal works
Parameters
| Model | JH7070T | |
|
Main Performance |
Bucket Capacity |
0.42m³ |
|
Travel Speed |
11.5km/h |
|
|
Rated loading capacity |
760kg |
|
|
Overall Weight of Machine |
3650kg |
|
|
Engine Model |
Xinchai / A498BT1-75B |
|
|
Rated Power Output/Revolution |
36.7kw/2500rpm |
|
|
System pressure |
21Mpa |
|
|
Pilot pressure |
2.5Mpa |
|
|
Main Size |
Length with Standard bucket |
3363 mm |
|
Shovel width |
1524 mm |
|
|
Canopy height |
1984 mm |
|
|
Maximum working height |
3677 mm |
|
|
Maximum bucket pin height |
2786 mm |
|
|
Maximum bucket horizontal height |
2618 mm |
|
|
Length (without bucket) |
2460 mm |
|
|
Departure angle |
20° |
|
|
Maximum bucket angle on flat ground |
24.5° |
|
|
Working Range |
Tilting Height |
1994 mm |
|
Loading Distance at Maximum Unloading Height |
684 mm |
|
|
wheelbase |
1572 mm |
|
|
Ground Clearance |
188 mm |
|
|
Tail Length |
688 mm |
|
|
Bucket Tilting Angle at Maximum Height |
86.3° |
|
|
Tilting Angle at Maximum Height |
49.1° |
|
