China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 6.5t small excavator | jh8065 in China. With abundant experience, we warmly welcome you to buy cheap 6.5t small excavator | jh8065 made in China here from our factory. For price consultation, contact us.
Key Features
JIAHE JH8065 6.5 Ton Crawler Excavator
The JIAHE JH8065 6.5 Ton Crawler Excavator is built for heavy-duty construction, landscaping, and earthmoving applications, combining strong digging performance with operator comfort and reliability.
Powered by Yanmar, Kohler, or Kubota engines with Euro 3/5 and EPA 4 emission options, the JH8065 delivers efficient power, low fuel consumption, and dependable performance in various working conditions.
Featuring a closed cabin with air conditioning and heater, air suspension seat, and a large display screen, the machine provides a comfortable and user-friendly operating environment for long working hours. The hydraulic pilot control system ensures precise and smooth operation, while the auxiliary hydraulic pipeline supports a wide range of attachments.
The key advantage of the JH8065 is its offset boom design, which improves machine balance and stability, making it ideal for heavy-duty operations with stronger lifting capacity and better working performance. Equipped with 400 mm steel tracks, 0.21 m³ bucket capacity, two-speed travel (2.4/4.3 km/h), and 28 MPa hydraulic pressure, it delivers powerful digging force and excellent durability.
Key Features
✅ 6.5 Ton Crawler Excavator
✅ Yanmar / Kohler / Kubota Engine Options
✅ Euro 3/5 & EPA 4 Emission Standards
✅ Closed Cabin with AC & Heater
✅ Air Suspension Seat + Large Display Screen
✅ Hydraulic Pilot Control System
✅ Auxiliary Hydraulic Pipeline for Attachments
✅ Offset Boom Design for Better Balance & Stability
✅ Heavy-Duty Steel Tracks (400 mm)
✅ Bucket Capacity: 0.21 m³
✅ Two-Speed Travel: 2.4 / 4.3 km/h
✅ Hydraulic Pressure: 28 MPa
JH8065 - A powerful and stable 6.5-ton excavator engineered for demanding jobs where strength, precision, and operator comfort matter.
Applications
Municipal:
pipe reconstruction, road widening, bridge maintenance.
Infrastructure:
foundation excavation, roadbed filling, site leveling.
Agricultural water conservancy:
farmland reconstruction, river dredging.
Mining & earthwork:
heavy excavation, loading, quarry work.
Demolition:
concrete breaking, waste handling.
Parameters
| Model | JH8065 | |
|
>>>> SPECIFICATIONS: |
||
|
ENGINE |
Emission Standard |
Euro V /EPA |
|
Make /Model |
Kubota/V2607 |
|
|
Power /Rotation speed |
42kw@2000rpm |
|
|
Type |
Diesel with water-cooled, |
|
|
TRACK SYSTEM |
Maximum Travel speed |
2.4/4.3 km/h |
|
Width of track shoe |
400mm |
|
|
Number of track shoe per side |
40pcs |
|
|
Number of upper roller per side |
1 |
|
|
Number of bottom roller per side |
5 |
|
|
PERFORMANCE PARAMETER |
Standard Bucket capacity |
0.21m³ |
|
Swing speed |
11rpm |
|
|
Maximum Grade ability |
35°(70%) |
|
|
Maximum Bucket digging force |
48KN |
|
|
Maximum Arm digging force |
35KN |
|
|
Hydraulic system pressure |
28Mpa |
|
|
Machine weight |
5900kg |
|
|
Fuel tank |
87L |
|
|
Hydraulic oil tank |
100L |
|
Main Dimensions
|
MACHINE SIZE |
Overall dimension (L*W*H) |
5802mm*1960mm*2420mm |
|
Height of cabin |
2600mm |
|
|
Track length on ground(Axle base) |
1990mm |
|
|
Track gauge |
1560mm |
|
|
Minimum Ground clearance |
353mm |
|
|
Swing radius at tail |
1520mm |
|
|
WORKING RANGE |
Maximum Digging height |
5928mm |
|
Maximum Dumping height |
4228mm |
|
|
Maximum Digging depth |
4158mm |
|
|
Maximum Vertical digging depth |
3458mm |
|
|
Maximum Digging radius |
6162mm |
|
|
Minimum swing radius |
2389mm |
|
|
Maximum Lifting height of blade |
380mm |
|
|
Maximum Cutting depth of blade |
455mm |
